4DZV image
Deposition Date 2012-03-01
Release Date 2012-05-02
Last Version Date 2023-11-15
Entry Detail
PDB ID:
4DZV
Keywords:
Title:
Complex of 4-alpha/beta bound to gp41-5
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.10 Å
R-Value Free:
0.22
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:gp41-5
Chain IDs:A
Chain Length:198
Number of Molecules:1
Biological Source:Synthetic construct
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
B3E B GLU (3S)-3-AMINOHEXANEDIOIC ACID
HMR B ARG BETA-HOMOARGININE
Ligand Molecules
Primary Citation
Enhancement of alpha-helix mimicry by an alpha / beta-peptide foldamer via incorporation of a dense ionic side-chain array.
J.Am.Chem.Soc. 134 7317 7320 (2012)
PMID: 22524614 DOI: 10.1021/ja302428d

Abstact

We report a new method for preorganization of α/β-peptide helices, based on the use of a dense array of acidic and basic side chains. Previously we have used cyclically constrained β residues to promote α/β-peptide helicity; here we show that an engineered ion pair array can be comparably effective, as indicated by mimicry of the CHR domain of HIV protein gp41. The new design is effective in biochemical and cell-based infectivity assays; however, the resulting α/β-peptide is susceptible to proteolysis. This susceptibility was addressed via introduction of a few cyclic β residues near the cleavage site, to produce the most stable, effective α/β-peptide gp41 CHR analogue identified. Crystal structures of an α- and α/β-peptide (each involved in a gp41-mimetic helix bundle) that contain the dense acid/base residue array manifest disorder in the ionic side chains, but there is little side-chain disorder in analogous α- and α/β-peptide structures with a sparser ionic side-chain array. These observations suggest that dense arrays of complementary acidic and basic residues can provide conformational stabilization via Coulombic attractions that do not require entropically costly ordering of side chains.
