3VHX image
Deposition Date 2011-09-12
Release Date 2012-05-16
Last Version Date 2023-11-08
Entry Detail
PDB ID:
3VHX
Title:
The crystal structure of Arf6-MKLP1 (Mitotic kinesin-like protein 1) complex
Biological Source:
Source Organism:
Mus musculus (Taxon ID: 10090)
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.81 Å
R-Value Free:
0.23
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1 21 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:ADP-ribosylation factor 6
Gene (Uniprot):Arf6
Mutations:Q67L
Chain IDs:A, C, E, G
Chain Length:172
Number of Molecules:4
Biological Source:Mus musculus
Polymer Type:polypeptide(L)
Molecule:Kinesin-like protein KIF23
Gene (Uniprot):KIF23
Chain IDs:B, D, F, H
Chain Length:120
Number of Molecules:4
Biological Source:Homo sapiens
Primary Citation
Structural basis for Arf6-MKLP1 complex formation on the Flemming body responsible for cytokinesis
Embo J. 31 2590 2603 (2012)
PMID: 22522702 DOI: 10.1038/emboj.2012.89

Abstact

A small GTPase, Arf6, is involved in cytokinesis by localizing to the Flemming body (the midbody). However, it remains unknown how Arf6 contributes to cytokinesis. Here, we demonstrate that Arf6 directly interacts with mitotic kinesin-like protein 1 (MKLP1), a Flemming body-localizing protein essential for cytokinesis. The crystal structure of the Arf6-MKLP1 complex reveals that MKLP1 forms a homodimer flanked by two Arf6 molecules, forming a 2:2 heterotetramer containing an extended β-sheet composed of 22 β-strands that spans the entire heterotetramer, suitable for interaction with a concave membrane surface at the cleavage furrow. We show that, during cytokinesis, Arf6 is first accumulated around the cleavage furrow and, prior to abscission, recruited onto the Flemming body via interaction with MKLP1. We also show by structure-based mutagenesis and siRNA-mediated knockdowns that the complex formation is required for completion of cytokinesis. A model based on these results suggests that the Arf6-MKLP1 complex plays a crucial role in cytokinesis by connecting the microtubule bundle and membranes at the cleavage plane.
