3VB5 image
Deposition Date 2011-12-31
Release Date 2012-12-12
Last Version Date 2024-10-30
Entry Detail
PDB ID:
3VB5
Title:
Crystal structure of SARS-CoV 3C-like protease with C4Z
Biological Source:
Source Organism:
SARS coronavirus (Taxon ID: 227859)
(Taxon ID: )
Host Organism:
Method Details:
Experimental Method:
Resolution:
1.95 Å
R-Value Free:
0.23
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1 21 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:3C-like proteinase
Gene (Uniprot):1a
Chain IDs:A, B
Chain Length:306
Number of Molecules:2
Biological Source:SARS coronavirus
Polymer Type:polypeptide(L)
Molecule:C4Z inhibitor
Chain IDs:C (auth: E), D (auth: F)
Chain Length:5
Number of Molecules:2
Biological Source:
Ligand Molecules
Peptide-like Molecules
PRD_000911
Primary Citation
Design, synthesis and crystallographic analysis of nitrile-based broad-spectrum peptidomimetic inhibitors for coronavirus 3C-like proteases
Eur.J.Med.Chem. 59C 1 6 (2012)
PMID: 23202846 DOI: 10.1016/j.ejmech.2012.10.053

Abstact

Coronaviral infection is associated with up to 5% of respiratory tract diseases. The 3C-like protease (3CL(pro)) of coronaviruses is required for proteolytic processing of polyproteins and viral replication, and is a promising target for the development of drugs against coronaviral infection. We designed and synthesized four nitrile-based peptidomimetic inhibitors with different N-terminal protective groups and different peptide length, and examined their inhibitory effect on the in-vitro enzymatic activity of 3CL(pro) of severe-acute-respiratory-syndrome-coronavirus. The IC(50) values of the inhibitors were in the range of 4.6-49 μM, demonstrating that the nitrile warhead can effectively inactivate the 3CL(pro) autocleavage process. The best inhibitor, Cbz-AVLQ-CN with an N-terminal carbobenzyloxy group, was ~10x more potent than the other inhibitors tested. Crystal structures of the enzyme-inhibitor complexes showed that the nitrile warhead inhibits 3CL(pro) by forming a covalent bond with the catalytic Cys145 residue, while the AVLQ peptide forms a number of favourable interactions with the S1-S4 substrate-binding pockets. We have further showed that the peptidomimetic inhibitor, Cbz-AVLQ-CN, has broad-spectrum inhibition against 3CL(pro) from human coronavirus strains 229E, NL63, OC43, HKU1, and infectious bronchitis virus, with IC(50) values ranging from 1.3 to 3.7 μM, but no detectable inhibition against caspase-3. In summary, we have shown that the nitrile-based peptidomimetic inhibitors are effective against 3CL(pro), and they inhibit 3CL(pro) from a broad range of coronaviruses. Our results provide further insights into the future design of drugs that could serve as a first line defence against coronaviral infection.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
