3SI8 image
Deposition Date 2011-06-17
Release Date 2011-08-03
Last Version Date 2024-03-13
Entry Detail
PDB ID:
3SI8
Keywords:
Title:
Human DNA polymerase eta - DNA ternary complex with the 5'T of a CPD in the active site (TT2)
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
(Taxon ID: )
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.15 Å
R-Value Free:
0.25
R-Value Work:
0.24
R-Value Observed:
0.24
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:DNA polymerase eta
Gene (Uniprot):POLH
Chain IDs:A
Chain Length:435
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*TP*GP*CP*GP*TP*CP*AP*TP*A)-3')
Chain IDs:C (auth: P)
Chain Length:9
Number of Molecules:1
Biological Source:
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*TP*A*AP*CP*(TTD)P*AP*TP*GP*AP*CP*GP*C)-3')
Chain IDs:B (auth: T)
Chain Length:12
Number of Molecules:1
Biological Source:
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
TTD B DT CIS-SYN CYCLOBUTANE THYMINE DIMER
Primary Citation
Structure and mechanism of human DNA polymerase eta.
Nature 465 1044 1048 (2010)
PMID: 20577208 DOI: 10.1038/nature09196

Abstact

The variant form of the human syndrome xeroderma pigmentosum (XPV) is caused by a deficiency in DNA polymerase eta (Poleta), a DNA polymerase that enables replication through ultraviolet-induced pyrimidine dimers. Here we report high-resolution crystal structures of human Poleta at four consecutive steps during DNA synthesis through cis-syn cyclobutane thymine dimers. Poleta acts like a 'molecular splint' to stabilize damaged DNA in a normal B-form conformation. An enlarged active site accommodates the thymine dimer with excellent stereochemistry for two-metal ion catalysis. Two residues conserved among Poleta orthologues form specific hydrogen bonds with the lesion and the incoming nucleotide to assist translesion synthesis. On the basis of the structures, eight Poleta missense mutations causing XPV can be rationalized as undermining the molecular splint or perturbing the active-site alignment. The structures also provide an insight into the role of Poleta in replicating through D loop and DNA fragile sites.
