3PN8 image
Deposition Date 2010-11-18
Release Date 2010-12-15
Last Version Date 2024-10-30
Entry Detail
PDB ID:
3PN8
Keywords:
HYDROLASE
Title:
The crystal structure of 6-phospho-beta-glucosidase from Streptococcus mutans UA159
Biological Source:
Source Organism:
Streptococcus mutans (Taxon ID: 1309)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.69 Å
R-Value Free:
0.19
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 1 21 1
3PN8 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Putative phospho-beta-glucosidase
Gene (Uniprot):bgl
Chain IDs:A, B
Chain Length:480
Number of Molecules:2
Biological Source:Streptococcus mutans
UniProt ID:Q8DT00 Pfam ID:PF00232
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
FMT
PEG
SO4
Primary Citation
The crystal structure of 6-phospho-beta-glucosidase from Streptococcus mutants UA159
To be Published ? ? ? (?)
Primary Citation of related structures
3PN8
