3NIK image
Deposition Date 2010-06-16
Release Date 2010-09-15
Last Version Date 2023-11-01
Entry Detail
PDB ID:
3NIK
Title:
The structure of UBR box (REAA)
Biological Source:
Source Organism:
Saccharomyces cerevisiae (Taxon ID: 4932)
(Taxon ID: )
Host Organism:
Method Details:
Experimental Method:
Resolution:
1.85 Å
R-Value Free:
0.24
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 32
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:E3 ubiquitin-protein ligase UBR1
Gene (Uniprot):UBR1
Chain IDs:A, B, C (auth: D), D (auth: F)
Chain Length:82
Number of Molecules:4
Biological Source:Saccharomyces cerevisiae
Polymer Type:polypeptide(L)
Molecule:Peptide REAA
Chain IDs:E (auth: X)
Chain Length:4
Number of Molecules:1
Biological Source:
Ligand Molecules
Primary Citation
Structural basis for the recognition of N-end rule substrates by the UBR box of ubiquitin ligases
Nat.Struct.Mol.Biol. 17 1175 1181 (2010)
PMID: 20835240 DOI: 10.1038/nsmb.1907

Abstact

The N-end rule pathway is a regulated proteolytic system that targets proteins containing destabilizing N-terminal residues (N-degrons) for ubiquitination and proteasomal degradation in eukaryotes. The N-degrons of type 1 substrates contain an N-terminal basic residue that is recognized by the UBR box domain of the E3 ubiquitin ligase UBR1. We describe structures of the UBR box of Saccharomyces cerevisiae UBR1 alone and in complex with N-degron peptides, including that of the cohesin subunit Scc1, which is cleaved and targeted for degradation at the metaphase-anaphase transition. The structures reveal a previously unknown protein fold that is stabilized by a novel binuclear zinc center. N-terminal arginine, lysine or histidine side chains of the N-degron are coordinated in a multispecific binding pocket. Unexpectedly, the structures together with our in vitro biochemical and in vivo pulse-chase analyses reveal a previously unknown modulation of binding specificity by the residue at position 2 of the N-degron.
