3LAE image
Deposition Date 2010-01-06
Release Date 2010-01-19
Last Version Date 2024-11-20
Entry Detail
PDB ID:
3LAE
Keywords:
MEMBRANE PROTEIN
Title:
The crystal structure of a functionally unknown conserved protein from Haemophilus influenzae Rd KW20
Biological Source:
Source Organism:
Haemophilus influenzae (Taxon ID: 727)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.45 Å
R-Value Free:
0.22
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
C 2 2 21
3LAE validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:UPF0053 protein HI0107
Gene (Uniprot):HI_0107
Chain IDs:A
Chain Length:81
Number of Molecules:1
Biological Source:Haemophilus influenzae
UniProt ID:Q57017 Pfam ID:PF03471
Polymer Type:polypeptide(L)
Molecule:Unknown peptide fragment
Chain IDs:B (auth: X)
Chain Length:3
Number of Molecules:1
Biological Source:
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
EDO
PO4
Primary Citation
The crystal structure of a functionally unknown conserved protein from Haemophilus influenzae Rd KW20
To be Published ? ? ? (?)
Primary Citation of related structures
2O1R
