3KNB image
Deposition Date 2009-11-12
Release Date 2009-12-01
Last Version Date 2024-02-21
Entry Detail
PDB ID:
3KNB
Title:
Crystal structure of the titin C-terminus in complex with obscurin-like 1
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
1.40 Å
R-Value Free:
0.19
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 31
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Titin
Gene (Uniprot):TTN
Chain IDs:A
Chain Length:100
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Obscurin-like protein 1
Gene (Uniprot):OBSL1
Chain IDs:B
Chain Length:107
Number of Molecules:1
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Molecular basis of the head-to-tail assembly of giant muscle proteins obscurin-like 1 and titin.
Embo Rep. 11 534 540 (2010)
PMID: 20489725 DOI: 10.1038/embor.2010.65

Abstact

Large filament proteins in muscle sarcomeres comprise many immunoglobulin-like domains that provide a molecular platform for self-assembly and interactions with heterologous protein partners. We have unravelled the molecular basis for the head-to-tail interaction of the carboxyl terminus of titin and the amino-terminus of obscurin-like-1 by X-ray crystallography. The binary complex is formed by a parallel intermolecular beta-sheet that presents a novel immunoglobulin-like domain-mediated assembly mechanism in muscle filament proteins. Complementary binding data show that the assembly is entropy-driven rather than dominated data by specific polar interactions. The assembly observed leads to a V-shaped zipper-like arrangement of the two filament proteins.
