3IGM image
Deposition Date 2009-07-28
Release Date 2009-11-10
Last Version Date 2024-11-06
Entry Detail
PDB ID:
3IGM
Title:
A 2.2A crystal structure of the AP2 domain of PF14_0633 from P. falciparum, bound as a domain-swapped dimer to its cognate DNA
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.20 Å
R-Value Free:
0.26
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
C 2 2 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PF14_0633 protein
Gene (Uniprot):PF3D7_1466400
Chain IDs:A (auth: B), D (auth: A)
Chain Length:77
Number of Molecules:2
Biological Source:Plasmodium falciparum
Polymer Type:polydeoxyribonucleotide
Molecule:5'-D(*TP*GP*CP*AP*TP*GP*CP*A)-3'
Chain IDs:B (auth: W), C (auth: X), E (auth: C), F (auth: D)
Chain Length:8
Number of Molecules:4
Biological Source:
Primary Citation
Structural Determinants of DNA Binding by a P. falciparum ApiAP2 Transcriptional Regulator.
J.Mol.Biol. 395 558 567 (2010)
PMID: 19913037 DOI: 10.1016/j.jmb.2009.11.004

Abstact

Putative transcription factors have only recently been identified in the Plasmodium spp., with the major family of regulators comprising the Apicomplexan Apetala2 (AP2) proteins. To better understand the DNA-binding mechanisms of these transcriptional regulators, we characterized the structure and in vitro function of an AP2 DNA-binding domain from a prototypical Apicomplexan AP2 protein, PF14_0633 from Plasmodium falciparum. The X-ray crystal structure of the PF14_0633 AP2 domain bound to DNA reveals a beta-sheet fold that binds the DNA major groove through base-specific and backbone contacts; a prominent alpha-helix supports the beta-sheet structure. Substitution of predicted DNA-binding residues with alanine weakened or eliminated DNA binding in solution. In contrast to plant AP2 domains, the PF14_0633 AP2 domain dimerizes upon binding to DNA through a domain-swapping mechanism in which the alpha-helices of the AP2 domains pack against the beta-sheets of the dimer mates. DNA-induced dimerization of PF14_0633 may be important for tethering two distal DNA loci together in the nucleus and/or for inducing functional rearrangements of its domains to facilitate transcriptional regulation. Consistent with a multisite binding mode, at least two copies of the consensus sequence recognized by PF14_0633 are present upstream of a previously identified group of sporozoite-stage genes. Taken together, these findings illustrate how Plasmodium has adapted the AP2 DNA-binding domain for genome-wide transcriptional regulation.
