3DKB image
Deposition Date 2008-06-24
Release Date 2008-07-08
Last Version Date 2024-02-21
Entry Detail
PDB ID:
3DKB
Keywords:
Title:
Crystal Structure of A20, 2.5 angstrom
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.24
R-Value Work:
0.20
Space Group:
P 32
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Tumor necrosis factor, alpha-induced protein 3
Gene (Uniprot):TNFAIP3
Chain IDs:A, B, C, D, E, F
Chain Length:390
Number of Molecules:6
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Molecular basis for the unique deubiquitinating activity of the NF-kappaB inhibitor A20
J.Mol.Biol. 376 526 540 (2008)
PMID: 18164316 DOI: 10.1016/j.jmb.2007.11.092

Abstact

Nuclear factor kappaB (NF-kappaB) activation in tumor necrosis factor, interleukin-1, and Toll-like receptor pathways requires Lys63-linked nondegradative polyubiquitination. A20 is a specific feedback inhibitor of NF-kappaB activation in these pathways that possesses dual ubiquitin-editing functions. While the N-terminal domain of A20 is a deubiquitinating enzyme (DUB) for Lys63-linked polyubiquitinated signaling mediators such as TRAF6 and RIP, its C-terminal domain is a ubiquitin ligase (E3) for Lys48-linked degradative polyubiquitination of the same substrates. To elucidate the molecular basis for the DUB activity of A20, we determined its crystal structure and performed a series of biochemical and cell biological studies. The structure reveals the potential catalytic mechanism of A20, which may be significantly different from papain-like cysteine proteases. Ubiquitin can be docked onto a conserved A20 surface; this interaction exhibits charge complementarity and no steric clash. Surprisingly, A20 does not have specificity for Lys63-linked polyubiquitin chains. Instead, it effectively removes Lys63-linked polyubiquitin chains from TRAF6 without dissembling the chains themselves. Our studies suggest that A20 does not act as a general DUB but has the specificity for particular polyubiquitinated substrates to assure its fidelity in regulating NF-kappaB activation in the tumor necrosis factor, interleukin-1, and Toll-like receptor pathways.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
