3D6G image
Deposition Date 2008-05-19
Release Date 2009-06-16
Last Version Date 2024-10-16
Entry Detail
PDB ID:
3D6G
Keywords:
Title:
Fc fragment of IgG1 (Herceptin) with protein-A mimetic peptide dendrimer ligand.
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.30 Å
R-Value Free:
0.25
R-Value Work:
0.18
R-Value Observed:
0.19
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Ig gamma-1 chain C region
Gene (Uniprot):IGHG1
Chain IDs:A, B
Chain Length:210
Number of Molecules:2
Biological Source:Homo sapiens
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Ligand Molecules
Primary Citation
Structural characterization of a Protein A mimetic peptide dendrimer bound to human IgG.
J.Phys.Chem.B 113 16268 16275 (2009)
PMID: 19924842 DOI: 10.1021/jp909405b

Abstact

Understanding the chemical physical properties of protein binding sites is at the basis of the rational design of protein ligands. The hinge region of the Fc fragment of immunoglobulin G is an important and well characterized protein binding site, known to interact with several natural proteins and synthetic ligands. Here, we report structural evidence that a Staphylococcus aureus Protein A mimetic peptide dendrimer, deduced by a combinatorial approach, binds close to the Cgamma2/Cgamma3 interface of the constant fragment of a human IgG1 molecule, partially hindering the Protein A binding site. The X-ray analysis evidenced a primary binding site located between a terminal Arg residue of the ligand peptidic arm and a hydrophobic protein site consisting of Val308, Leu309, and His310. A molecular dynamic analysis of the model derived from the X-ray structure showed that in water at room temperature the complex is further stabilized by the formation of at least one more contact between a terminal Arg residue of the second arm of the peptide and the carboxylic group of a protein amino acid, such as Glu318, Asp312, or Asp280. It appears thus that stability of the Fc-dendrimer complex is determined by the synergetic formation of multiple bonds of different nature between the dendrimer arms and the protein accessible sites. The electrostatic and van der Waals energies of the complex were monitored during the MD simulations and confirmed the energetic stability of the two interactions.
