3AV1 image
Deposition Date 2011-02-18
Release Date 2011-06-01
Last Version Date 2023-11-01
Entry Detail
PDB ID:
3AV1
Title:
The human nucleosome structure containing the histone variant H3.2
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.29
R-Value Work:
0.24
R-Value Observed:
0.24
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Histone H3.2
Gene (Uniprot):H3C15, H3C14, H3C13
Chain IDs:A, E
Chain Length:139
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Histone H4
Gene (Uniprot):H4C1, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4C11, H4C12, H4C13, H4C14, H4C15, H4C16
Chain IDs:B, F
Chain Length:106
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Histone H2A type 1-B/E
Gene (Uniprot):H2AC4, H2AC8
Chain IDs:C, G
Chain Length:133
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Histone H2B type 1-J
Gene (Uniprot):H2BC11
Chain IDs:D, H
Chain Length:129
Number of Molecules:2
Biological Source:Homo sapiens
Polymer Type:polydeoxyribonucleotide
Molecule:146-MER DNA
Chain IDs:I, J
Chain Length:146
Number of Molecules:2
Biological Source:
Primary Citation
Structures of human nucleosomes containing major histone H3 variants
Acta Crystallogr.,Sect.D 67 578 583 (2011)
PMID: 21636898 DOI: 10.1107/S0907444911014818

Abstact

The nucleosome is the fundamental repeating unit of chromatin, via which genomic DNA is packaged into the nucleus in eukaryotes. In the nucleosome, two copies of each core histone, H2A, H2B, H3 and H4, form a histone octamer which wraps 146 base pairs of DNA around itself. All of the core histones except for histone H4 have nonallelic isoforms called histone variants. In humans, eight histone H3 variants, H3.1, H3.2, H3.3, H3T, H3.5, H3.X, H3.Y and CENP-A, have been reported to date. Previous studies have suggested that histone H3 variants possess distinct functions in the formation of specific chromosome regions and/or in the regulation of transcription and replication. H3.1, H3.2 and H3.3 are the most abundant H3 variants. Here, crystal structures of human nucleosomes containing either H3.2 or H3.3 have been solved. The structures were essentially the same as that of the H3.1 nucleosome. Since the amino-acid residues specific for H3.2 and H3.3 are located on the accessible surface of the H3/H4 tetramer, they may be potential interaction sites for H3.2- and H3.3-specific chaperones.
