2RGS image
Deposition Date 2007-10-05
Release Date 2008-10-07
Last Version Date 2024-11-13
Entry Detail
PDB ID:
2RGS
Keywords:
IMMUNE SYSTEM
Title:
FC-fragment of monoclonal antibody IGG2B from Mus musculus
Biological Source:
Source Organism:
Mus musculus (Taxon ID: 10090)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.13 Å
R-Value Free:
0.21
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
C 1 2 1
2RGS validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ig gamma-2B heavy chain
Gene (Uniprot):Ighg2b
Chain IDs:A, B
Chain Length:218
Number of Molecules:2
Biological Source:Mus musculus
UniProt ID:P01867 Pfam ID:PF07654
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Primary Citation
New insights into intra- and intermolecular interactions of immunoglobulins: crystal structure of mouse IgG2b-Fc at 2.1-A resolution
Immunology 126 378 385 (2008)
PMID: 18783468 DOI: 10.1111/j.1365-2567.2008.02904.x

Abstact

The structure of the Fc fragment of monoclonal antibody IgG2b from hybridom M75 of Mus musculus has been determined by single crystal X-ray diffraction. This is the first report of the structure of the murine immunoglobulin isotype IgG2b. The structure refined at 2.1 A resolution provides more detailed structural information about native oligosaccharides than was previously available. High-quality Fourier maps provide a clear identification of alpha-l-fucose with partial occupancy in the first branch of the antennary oligosaccharides. A unique Fc:Fc interaction was observed at the C(H)2-C(H)3 interface.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
2RGS
