2M39 image
Deposition Date 2013-01-15
Release Date 2013-11-27
Last Version Date 2024-05-15
Entry Detail
PDB ID:
2M39
Keywords:
Title:
The solution structure of 3',5'-LINKED 2'-O-(2-METHOXYETHYL)-RNA DUPLEX
Biological Source:
Source Organism:
Synthetic (Taxon ID: 32630)
Method Details:
Experimental Method:
Conformers Calculated:
50
Conformers Submitted:
9
Selection Criteria:
structures with the lowest energy
Macromolecular Entities
Polymer Type:polyribonucleotide
Molecule:RNA (5'-R(*(C5L)P*(G48)P*(C5L)P*(G48)P*(A44)P*(A44)P*(T39)P*(T39)P*(C5L)P*(G48)P*(C5L)P*DG)-3')
Chain IDs:A, B
Chain Length:12
Number of Molecules:2
Biological Source:Synthetic
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
A44 A A ?
C5L A C ?
G48 A G ?
T39 A DT ?
Ligand Molecules
Primary Citation
NMR structure of 2'-O-(2-methoxyethyl) modified and C5-methylated RNA dodecamer duplex.
Biochimie 95 2385 2391 (2013)
PMID: 24012551 DOI: 10.1016/j.biochi.2013.08.025

Abstact

The solution-state structure of 2'-O-(2-methoxyethly) substituted dodecamer r(*CG*CGAA*U*U*CG*C)d(G), 2'-MOE RNA, with all cytosines and uracils methylated at the C5-position has been determined by NMR spectroscopy. The chemical modifications were used to improve the oligonucleotide's drug-like properties. The 2'-MOE group drives pseudorotational equilibrium of the ribofuranose moiety to the N-type conformation and supposedly results in structural preorganization leading to high affinity of a modified oligonucleotide towards its complementary biological target, improved pharmacokinetic and toxicological properties. The high melting temperature of the antiparallel duplex structure adopted by 2'-MOE RNA was explained through the formation of a stable A-form RNA consistent with effective base-pairing and stacking interactions. The comparison of the solution-state structure with the crystal structure of a non-methylated analogue shows an increase in the stacking at the base pair steps for the C5-methylated 2'-MOE RNA duplex. The MOE substituents adopt a well-defined structure in the minor groove with the predominant gauche conformations around the ethylene bond.
