2HI7 image
Deposition Date 2006-06-29
Release Date 2006-12-05
Last Version Date 2024-11-20
Entry Detail
PDB ID:
2HI7
Keywords:
Title:
Crystal structure of DsbA-DsbB-ubiquinone complex
Biological Source:
Source Organism:
Escherichia coli (Taxon ID: 562)
Host Organism:
Method Details:
Experimental Method:
Resolution:
3.70 Å
R-Value Free:
0.36
R-Value Work:
0.34
R-Value Observed:
0.34
Space Group:
P 42 21 2
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Thiol:disulfide interchange protein dsbA
Gene (Uniprot):dsbA
Mutagens:C33A
Chain IDs:A
Chain Length:189
Number of Molecules:1
Biological Source:Escherichia coli
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Disulfide bond formation protein B
Gene (Uniprot):dsbB
Mutagens:C8A,C49V,C130S
Chain IDs:B
Chain Length:176
Number of Molecules:1
Biological Source:Escherichia coli
Primary Citation
Crystal Structure of the DsbB-DsbA Complex Reveals a Mechanism of Disulfide Bond Generation
Cell(Cambridge,Mass.) 127 789 801 (2006)
PMID: 17110337 DOI: 10.1016/j.cell.2006.10.034

Abstact

Oxidation of cysteine pairs to disulfide requires cellular factors present in the bacterial periplasmic space. DsbB is an E. coli membrane protein that oxidizes DsbA, a periplasmic dithiol oxidase. To gain insight into disulfide bond formation, we determined the crystal structure of the DsbB-DsbA complex at 3.7 A resolution. The structure of DsbB revealed four transmembrane helices and one short horizontal helix juxtaposed with Cys130 in the mobile periplasmic loop. Whereas DsbB in the resting state contains a Cys104-Cys130 disulfide, Cys104 in the binary complex is engaged in the intermolecular disulfide bond and captured by the hydrophobic groove of DsbA, resulting in separation from Cys130. This cysteine relocation prevents the backward resolution of the complex and allows Cys130 to approach and activate the disulfide-generating reaction center composed of Cys41, Cys44, Arg48, and ubiquinone. We propose that DsbB is converted by its specific substrate, DsbA, to a superoxidizing enzyme, capable of oxidizing this extremely oxidizing oxidase.
