2GYS image
Deposition Date 2006-05-09
Release Date 2006-06-20
Last Version Date 2024-10-30
Entry Detail
PDB ID:
2GYS
Keywords:
SIGNALING PROTEIN, CYTOKINE
Title:
2.7 A structure of the extracellular domains of the human beta common receptor involved in IL-3, IL-5, and GM-CSF signalling
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Trichoplusia ni
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.70 Å
R-Value Free:
0.26
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
H 3
2GYS validation report
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cytokine receptor common beta chain
Mutations:N328Q
Chain IDs:A, B
Chain Length:419
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:P32927 Pfam ID:PF21460
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Ligand Molecules
NA
Primary Citation
An improved resolution structure of the human beta common receptor involved in IL-3, IL-5 and GM-CSF signalling which gives better definition of the high-affinity binding epitope.
Acta Crystallogr.,Sect.F 62 509 513 (2006)
PMID: 16754968 DOI: 10.1107/S1744309106016812

Abstact

X-ray diffraction has been used to produce and refine a model of the extracellular domains of the beta common cytokine receptor. A minor improvement in resolution has resulted in improved electron-density maps, which have given a clearer indication of the position and stabilization of the key residues Tyr15, Phe79, Tyr347, His349, Ile350 and Tyr403 in the elbow region between domain 1 and domain 4 of the dimer-related molecule.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
1GH7
