2F9D image
Entry Detail
PDB ID:
2F9D
Title:
2.5 angstrom resolution structure of the spliceosomal protein p14 bound to region of SF3b155
Biological Source:
Source Organism:
Host Organism:
PDB Version:
Deposition Date:
2005-12-05
Release Date:
2006-01-24
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.27
R-Value Work:
0.22
R-Value Observed:
0.22
Space Group:
C 2 2 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Description:Pre-mRNA branch site protein p14
Chain IDs:A, B
Chain Length:125
Number of Molecules:2
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Description:Splicing factor 3B subunit 1
Chain IDs:C (auth: P), D (auth: Q)
Chain Length:43
Number of Molecules:2
Biological Source:Homo sapiens
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE C MET SELENOMETHIONINE
Primary Citation
Crystal structure of a core spliceosomal protein interface
Proc.Natl.Acad.Sci.Usa 103 1266 1271 (2006)
PMID: 16432215 DOI: 10.1073/pnas.0508048103

Abstact

The precise excision of introns from precursor mRNAs (pre-mRNAs) in eukaryotes is accomplished by the spliceosome, a complex assembly containing five small nuclear ribonucleoprotein (snRNP) particles. Human p14, a component of the spliceosomal U2 and U11/U12 snRNPs, has been shown to associate directly with the pre-mRNA branch adenosine early in spliceosome assembly and within the fully assembled spliceosome. Here we report the 2.5-A crystal structure of a complex containing p14 and a peptide derived from the p14-associated U2 snRNP component SF3b155. p14 contains an RNA recognition motif (RRM), the surface of which is largely occluded by a C-terminal alpha-helix and a portion of the SF3b155 peptide. An analysis of RNA.protein crosslinking to wild-type and mutant p14 shows that the branch adenosine directly interacts with a conserved aromatic within a pocket on the surface of the complex. This result, combined with a comparison of the structure with known RRMs and pseudoRRMs as well as model-building by using the electron cryomicroscopy structure of a spliceosomal U11/U12 di-snRNP, suggests that p14.SF3b155 presents a noncanonical surface for RNA recognition at the heart of the mammalian spliceosome.
