ISDA

Deposition Date 2005-11-29

Release Date 2005-12-13

Last Version Date 2023-08-23

Entry Detail

PDB ID:

2F70

Keywords:

HYDROLASE

Title:

Protein tyrosine phosphatase 1B with sulfamic acid inhibitors

Biological Source:

Source Organism:

Homo sapiens (Taxon ID: 9606)

Host Organism:

Escherichia coli BL21(DE3)

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.12 Å

R-Value Free:

0.19

R-Value Work:

0.15

R-Value Observed:

0.16

Space Group:

P 31 2 1

Download Validation Report

Macromolecular Entities

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Tyrosine-protein phosphatase, non-receptor type 1
Gene (Uniprot):PTPN1
Chain IDs:A
Chain Length:298
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P18031 Pfam ID:PF00102 EC:3.1.3.48

Ligand Molecules

UN6

Primary Citation

1,2,3,4-Tetrahydroisoquinolinyl sulfamic acids as phosphatase PTP1B inhibitors

Klopfenstein, S.R, Evdokimov, A.G, Colson, A.-O, Fairweather, N.T, Neuman, J.J, Maier, M.B, Gray, J.L, Gerwe, G.S, Stake, G.E, Howard, B.W, Farmer, J.A, Pokross, M.E, Downs, T.R, Kasibhatla, B, Peters, K.G.Show

Bioorg.Med.Chem.Lett. 16 1574 1578 (2006)

PMID: 16386905 DOI: 10.1016/j.bmcl.2005.12.051

Abstact

High-throughput screening of the P&GP corporate repository against several protein tyrosine phosphatases identified the sulfamic acid moiety as potential phosphotyrosine mimetic. Incorporation of the sulfamic acid onto a 1,2,3,4-tetrahydroisoquinoline scaffold provided a promising starting point for PTP1B inhibitor design.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
