2F3E image
Deposition Date 2005-11-21
Release Date 2006-09-05
Last Version Date 2024-11-20
Entry Detail
PDB ID:
2F3E
Keywords:
Title:
Crystal Structure of the Bace complex with AXQ093, a macrocyclic inhibitor
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.11 Å
R-Value Free:
0.23
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1 21 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Beta-secretase 1
Gene (Uniprot):BACE1
Chain IDs:A, B, C
Chain Length:402
Number of Molecules:3
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Structure-based design and synthesis of macroheterocyclic peptidomimetic inhibitors of the aspartic protease beta-site amyloid precursor protein cleaving enzyme (BACE).
J.Med.Chem. 49 4544 4567 (2006)
PMID: 16854060 DOI: 10.1021/jm060154a

Abstact

Based on the X-ray cocrystal structure of the Tang-Ghosh heptapeptide inhibitor 1 (OM00-3), a series of macroheterocyclic analogues were designed and synthesized. Analogues containing dithia, dioxa, oxathia, and carbathia macrocycles were synthesized by methods relying on ring-closing olefin metathesis for the dioxa analogues and by alkylation of thiolates or bisthiolates for the others. Molecular modeling suggested that the incorporation of piperidine units appended to the macrocycles improved interactions through additional H-bonds and introduced further rigidity. These were synthesized in enantiomerically pure form using enzyme-catalyzed desymmetrization and diastereomer separation. Inhibitory activity on beta-site amyloid precursor protein cleaving enzyme (BACE) was observed with several macroheterocyclic inhibitors and structure-activity relationship (SAR) correlations were deduced. Cocrystal structures of two synthetic analogues revealed interesting and unexpected binding interactions.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
