2EVG image
Deposition Date 2005-10-31
Release Date 2006-03-21
Last Version Date 2023-08-23
Entry Detail
PDB ID:
2EVG
Keywords:
Title:
Structure of a Ndt80-DNA complex (MSE mutant mA7T)
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
1.55 Å
R-Value Free:
0.18
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
C 2 2 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:NDT80 protein
Gene (Uniprot):NDT80
Mutations:s146g, i200t
Chain IDs:C (auth: A)
Chain Length:345
Number of Molecules:1
Biological Source:Saccharomyces cerevisiae
Primary Citation
Principles of Protein-DNA Recognition Revealed in the Structural Analysis of Ndt80-MSE DNA Complexes.
Structure 14 555 565 (2006)
PMID: 16531239 DOI: 10.1016/j.str.2005.11.017

Abstact

The Saccharomyces cerevisiae transcription factor Ndt80 selectively binds a DNA consensus sequence (the middle sporulation element [MSE]) to activate gene expression after the successful completion of meiotic recombination. Here we report the X-ray crystal structures of Ndt80 bound to ten distinct MSE variants. Comparison of these structures with the structure of Ndt80 bound to a consensus MSE reveals structural principles that determine the DNA binding specificity of this transcription factor. The 5' GC-rich end of the MSE contains distinct 5'-YpG-3' steps that are recognized by arginine side chains through a combination of hydrogen bonding and cation-pi interactions. The 3' AT-rich region is recognized via minor groove contacts that sterically exclude the N2 atom of GC base pairs. The conformation of the AT-rich region is fixed by interactions with the protein that favor recognition of poly(A)-poly(T) versus mixed AT sequences through an avoidance of major groove steric clashes at 5'-ApT-3' steps.
