2CK3 image
Deposition Date 2006-04-10
Release Date 2006-05-08
Last Version Date 2023-12-13
Entry Detail
PDB ID:
2CK3
Keywords:
Title:
Azide inhibited bovine F1-ATPase
Biological Source:
Source Organism:
BOS TAURUS (Taxon ID: 9913)
Method Details:
Experimental Method:
Resolution:
1.95 Å
R-Value Free:
0.22
R-Value Work:
0.19
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:ATP SYNTHASE SUBUNIT ALPHA, MITOCHONDRIAL
Gene (Uniprot):ATP5F1A
Chain IDs:A, B, C
Chain Length:510
Number of Molecules:3
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:ATP SYNTHASE SUBUNIT BETA, MITOCHONDRIAL
Gene (Uniprot):ATP5F1B
Chain IDs:D, E, F
Chain Length:482
Number of Molecules:3
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:ATP SYNTHASE SUBUNIT GAMMA, MITOCHONDRIAL
Gene (Uniprot):ATP5F1C
Chain IDs:G
Chain Length:272
Number of Molecules:1
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:ATP SYNTHASE SUBUNIT DELTA, MITOCHONDRIAL
Gene (Uniprot):ATP5F1D
Chain IDs:H
Chain Length:146
Number of Molecules:1
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:ATP SYNTHASE SUBUNIT EPSILON, MITOCHONDRIAL
Gene (Uniprot):ATP5F1E
Chain IDs:I
Chain Length:50
Number of Molecules:1
Biological Source:BOS TAURUS
Primary Citation

Abstact

In the structure of bovine F1-ATPase determined at 1.95-A resolution with crystals grown in the presence of ADP, 5'-adenylyl-imidodiphosphate, and azide, the azide anion interacts with the beta-phosphate of ADP and with residues in the ADP-binding catalytic subunit, betaDP. It occupies a position between the catalytically essential amino acids, beta-Lys-162 in the P loop and the "arginine finger" residue, alpha-Arg-373, similar to the site occupied by the gamma-phosphate in the ATP-binding subunit, betaTP. Its presence in the betaDP-subunit tightens the binding of the side chains to the nucleotide, enhancing its affinity and thereby stabilizing the state with bound ADP. This mechanism of inhibition appears to be common to many other ATPases, including ABC transporters, SecA, and DNA topoisomerase IIalpha. It also explains the stimulatory effect of azide on ATP-sensitive potassium channels by enhancing the binding of ADP.
