2BTJ image
Deposition Date 2005-06-01
Release Date 2005-06-23
Last Version Date 2023-12-13
Entry Detail
PDB ID:
2BTJ
Title:
Fluorescent Protein EosFP - red form
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.00 Å
R-Value Free:
0.23
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Green to red photoconvertible GFP-like protein EosFP
Chain IDs:B (auth: A), D (auth: B), F (auth: C), H (auth: D)
Chain Length:159
Number of Molecules:4
Biological Source:Lobophyllia hemprichii
Polymer Type:polypeptide(L)
Molecule:Green to red photoconvertible GFP-like protein EosFP
Chain IDs:A (auth: aa), C (auth: bb), E (auth: cc), G (auth: dd)
Chain Length:61
Number of Molecules:4
Biological Source:Lobophyllia hemprichii
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
NFA A PHE modified residue
RC7 B HIS chromophore
Primary Citation
Structural Basis for Photo-Induced Protein Cleavage and Green-to-Red Conversion of Fluorescent Protein Eosfp.
Proc.Natl.Acad.Sci.USA 102 9156 ? (2005)
PMID: 15964985 DOI: 10.1073/PNAS.0501874102

Abstact

Genetically encoded fusion constructs derived from fluorescent proteins (FPs) can be designed to report on a multitude of events and signals in cells, tissues, and entire organs without interfering with the complex machinery of life. EosFP is a novel FP from the scleractinian coral Lobophyllia hemprichii that switches its fluorescence emission from green (516 nm) to red (581 nm) upon irradiation with approximately 400-nm light. This property enables localized tagging of proteins and thus provides a valuable tool for tracking protein movements within live cells. Here, we present the x-ray structures of the green and red forms of WT EosFP. They reveal that formation of the red chromophore is associated with cleavage of the peptide backbone, with surprisingly little change elsewhere in the structure, and provide insights into the mechanism that generates this interesting posttranslational polypeptide modification.
