2BJ6 image
Deposition Date 2005-01-30
Release Date 2005-03-09
Last Version Date 2024-05-08
Entry Detail
PDB ID:
2BJ6
Title:
Crystal Structure of a decameric HNA-RNA hybrid
Biological Source:
Source Organism:
HOMO SAPIENS (Taxon ID: 9606)
Method Details:
Experimental Method:
Resolution:
2.60 Å
R-Value Free:
0.25
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
P 41 21 2
Macromolecular Entities
Polymer Type:polydeoxyribonucleotide
Molecule:SYNTHETIC HNA
Chain IDs:A, B, C, D
Chain Length:10
Number of Molecules:4
Biological Source:HOMO SAPIENS
Polymer Type:polyribonucleotide
Molecule:5'-R(*GP*GP*CP*AP*UP*UP*AP*CP*GP*GP)-3'
Chain IDs:E, F, G, H
Chain Length:10
Number of Molecules:4
Biological Source:HOMO SAPIENS
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
6HA A DA ?
6HC A DC ?
6HG A DG ?
6HT A DT ?
Ligand Molecules
Primary Citation

Abstact

The crystal structure of a decameric HNA/RNA (HNA = 2',3'-dideoxy-1',5'-anhydro-d-arabinohexitol nucleic acid) hybrid with the RNA sequence 5'-GGCAUUACGG-3' is the first crystal structure of a hybrid duplex between a naturally occurring nucleic acid and a strand, which is fully modified to contain a six-membered ring instead of ribose. The presence of four duplex helices in the asymmetric unit allows for a detailed discussion of hydration, which revealed a tighter spinelike backbone hydration for the HNA- than for the RNA-strands. The reinforced backbone hydration is suggested to contribute significantly to the exceptional stability of HNA-containing duplexes and might be one of the causes for the evolutionary preference for ribose-derived nucleic acids.
