2BDE image
Deposition Date 2005-10-20
Release Date 2005-12-06
Last Version Date 2024-11-13
Entry Detail
PDB ID:
2BDE
Keywords:
DNA BINDING PROTEIN
Title:
Crystal Structure of the cytosolic IMP-GMP specific 5'-nucleotidase (lpg0095) from Legionella pneumophila, Northeast Structural Genomics Target LgR1
Biological Source:
Source Organism:
Legionella pneumophila (Taxon ID: 446)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.90 Å
R-Value Free:
0.26
R-Value Work:
0.22
R-Value Observed:
0.22
Space Group:
I 41 2 2
2BDE validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:cytosolic IMP-GMP specific 5'-nucleotidase
Gene (Uniprot):lpg0095
Chain IDs:A
Chain Length:470
Number of Molecules:1
Biological Source:Legionella pneumophila
UniProt ID:Q5ZZB6 Pfam ID:PF05761 EC:3.1.3.5
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
SO4
Primary Citation
Crystal Structure of the cytosolic IMP-GMP specific 5'-nucleotidase (lpg0095) from Legionella pneumophila, Northeast Structural Genomics Target LgR1
To be Published ? ? ? (?)
Primary Citation of related structures
LGR1
