233D image
Deposition Date 1995-10-16
Release Date 1996-06-21
Last Version Date 2024-02-14
Entry Detail
PDB ID:
233D
Keywords:
Title:
THE CRYSTAL STRUCTURE ANALYSIS OF D(CGCGAASSCGCG)2: A SYNTHETIC DNA DODECAMER DUPLEX CONTAINING FOUR 4'-THIO-2'-DEOXYTHYMIDINE NUCLEOTIDES
Biological Source:
Source Organism:
(Taxon ID: ) (Taxon ID: )
Method Details:
Experimental Method:
Resolution:
2.40 Å
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*CP*GP*CP*GP*AP*AP*)-D(*(T49)P*(T49)P*)-D(*CP*GP*CP*G)-3')
Chain IDs:A, B
Chain Length:12
Number of Molecules:2
Biological Source:
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
T49 A DT S4'-2'DEOXYTHYMIDINE 5'-MONOPHOSPHATE
Primary Citation
The crystal structure analysis of d(CGCGAASSCGCG)2, a synthetic DNA dodecamer duplex containing four 4'-thio-2'-deoxythymidine nucleotides.
Nucleic Acids Res. 24 951 961 (1996)
PMID: 8600465 DOI: 10.1093/nar/24.5.951

Abstact

The crystal structure refinement of the synthetic dodecamer d(CGCGAASSCGCG), where S = 4'-thio-2'-deoxythymidine, has converged at R=0.201 for 2605 reflections with F > 2sigma(F) in the resolution range 8.0-2.4 A for a model consisting of the dodecamer duplex and 66 water molecules. A comparison of its structure with that of the native dodecamer d(CGCGAATTCGCG) has revealed that the major differences between the two structures is a change in the conformation of the sugar-phosphate backbone in the regions at and adjacent to the positions of the modified nucleosides. Examination of the fine structural parameters for each of the structures reveals that the thiosugars adopt a C3'-exo conformation in d(CGCGAASSCGCG), rather than the approximate C1'-exo conformation found for the analogous sugars in the structure of d(CGCGAATTCGCG). The observed differences in structure between the two duplexes may help to explain the enhanced resistance to nuclease digestion of synthetic oligonucleotides containing 4'-thio-2'-deoxynucleotides.
