1ZGL image
Deposition Date 2005-04-21
Release Date 2005-10-18
Last Version Date 2024-11-13
Entry Detail
PDB ID:
1ZGL
Keywords:
Title:
Crystal structure of 3A6 TCR bound to MBP/HLA-DR2a
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.80 Å
R-Value Free:
0.32
R-Value Work:
0.28
Space Group:
P 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:HLA class II histocompatibility antigen, DR alpha chain
Gene (Uniprot):HLA-DRA
Chain IDs:A, F (auth: D), K (auth: G), P (auth: J)
Chain Length:181
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:major histocompatibility complex, class II, DR beta 5
Chain IDs:B, G (auth: E), L (auth: H), Q (auth: K)
Chain Length:192
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:Myelin basic protein
Chain IDs:C, H (auth: F), M (auth: I), R (auth: L)
Chain Length:15
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:T cell receptor alpha chain
Gene (Uniprot):TRAC
Chain IDs:D (auth: M), I (auth: Q), N (auth: S), S (auth: U)
Chain Length:209
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:T cell receptor beta chain
Gene (Uniprot):TRBC1
Chain IDs:E (auth: P), J (auth: R), O (auth: T), T (auth: V)
Chain Length:249
Number of Molecules:4
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Structure of a human autoimmune TCR bound to a myelin basic protein self-peptide and a multiple sclerosis-associated MHC class II molecule.
Embo J. 24 2968 2979 (2005)
PMID: 16079912 DOI: 10.1038/sj.emboj.7600771

Abstact

Multiple sclerosis is mediated by T-cell responses to central nervous system antigens such as myelin basic protein (MBP). To investigate self-peptide/major histocompatibility complex (MHC) recognition and T-cell receptor (TCR) degeneracy, we determined the crystal structure, at 2.8 A resolution, of an autoimmune TCR (3A6) bound to an MBP self-peptide and the multiple sclerosis-associated MHC class II molecule, human leukocyte antigen (HLA)-DR2a. The complex reveals that 3A6 primarily recognizes the N-terminal portion of MBP, in contrast with antimicrobial and alloreactive TCRs, which focus on the peptide center. Moreover, this binding mode, which may be frequent among autoimmune TCRs, is compatible with a wide range of orientation angles of TCR to peptide/MHC. The interface is characterized by a scarcity of hydrogen bonds between TCR and peptide, and TCR-induced conformational changes in MBP/HLA-DR2a, which likely explain the low observed affinity. Degeneracy of 3A6, manifested by recognition of superagonist peptides bearing substitutions at nearly all TCR-contacting positions, results from the few specific interactions between 3A6 and MBP, allowing optimization of interface complementarity through variations in the peptide.
