1VKX image
Deposition Date 1997-09-17
Release Date 1998-12-09
Last Version Date 2024-10-16
Entry Detail
PDB ID:
1VKX
Title:
CRYSTAL STRUCTURE OF THE NFKB P50/P65 HETERODIMER COMPLEXED TO THE IMMUNOGLOBULIN KB DNA
Biological Source:
Source Organism:
Mus musculus (Taxon ID: 10090)
Method Details:
Experimental Method:
Resolution:
2.90 Å
R-Value Free:
0.32
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 43 21 2
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:PROTEIN (NF-KAPPA B P65 SUBUNIT)
Gene (Uniprot):Rela
Chain IDs:C (auth: A)
Chain Length:273
Number of Molecules:1
Biological Source:Mus musculus
Polymer Type:polypeptide(L)
Molecule:PROTEIN (NF-KAPPA B P50 SUBUNIT)
Gene (Uniprot):Nfkb1
Chain IDs:D (auth: B)
Chain Length:312
Number of Molecules:1
Biological Source:Mus musculus
Ligand Molecules
Primary Citation
Crystal structure of p50/p65 heterodimer of transcription factor NF-kappaB bound to DNA.
Nature 391 410 413 (1998)
PMID: 9450761 DOI: 10.1038/34956

Abstact

The NF-kappaB p50/p65 heterodimer is the classical member of the Rel family of transcription factors which regulate diverse cellular functions such as immune response, cell growth, and development. Other mammalian Rel family members, including the proteins p52, proto-oncoprotein c-Rel, and RelB, all have amino-terminal Rel-homology regions (RHRs). The RHR is responsible for the dimerization, DNA binding and cytosolic localization of these proteins by virtue of complex formation with inhibitor kappaB proteins. Signal-induced removal of kappaB inhibitors allows translocation of dimers to the cell nucleus and transcriptional regulation of kappaB DNA-containing genes. NF-kappaB specifically recognizes kappaB DNA elements with a consensus sequence of 5'-GGGRNYYYCC-3' (R is an unspecified purine; Y is an unspecified pyrimidine; and N is any nucleotide). Here we report the crystal structure at 2.9 A resolution of the p50/p65 heterodimer bound to the kappaB DNA of the intronic enhancer of the immunoglobulin light-chain gene. Our structure reveals a 5-base-pair 5' subsite for p50, and a 4-base-pair 3' subsite for p65. This structure indicates why the p50/p65 heterodimer interface is stronger than that of either homodimer. A comparison of this structure with those of other Rel dimers reveals that both subunits adopt variable conformations in a DNA-sequence-dependent manner. Our results explain the different behaviour of the p50/p65 heterodimer with heterologous promoters.
