1R71 image
Deposition Date 2003-10-17
Release Date 2004-06-01
Last Version Date 2024-02-14
Entry Detail
PDB ID:
1R71
Title:
Crystal Structure of the DNA binding domain of KorB in complex with the operator DNA
Biological Source:
Source Organism:
Escherichia coli (Taxon ID: 562)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.20 Å
R-Value Free:
0.25
R-Value Work:
0.19
R-Value Observed:
0.19
Space Group:
P 32 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Transcriptional repressor protein korB
Gene (Uniprot):korB
Chain IDs:I (auth: A), J (auth: B), K (auth: C), L (auth: D)
Chain Length:178
Number of Molecules:4
Biological Source:Escherichia coli
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
BRU A DU ?
Primary Citation
Sequence-specific DNA binding determined by contacts outside the helix-turn-helix motif of the ParB homolog KorB.
Nat.Struct.Mol.Biol. 11 656 663 (2004)
PMID: 15170177 DOI: 10.1038/nsmb773

Abstact

The KorB protein of the broad-host-range plasmid RP4 acts as a multifunctional regulator of plasmid housekeeping genes, including those responsible for replication, maintenance and conjugation. Additionally, KorB functions as the ParB analog of the plasmid's partitioning system. The protein structure consists of eight helices, two of which belong to a predicted helix-turn-helix motif. Each half-site of the palindromic operator DNA binds one copy of the protein in the major groove. As confirmed by mutagenesis, recognition specificity is based mainly on two side chain interactions outside the helix-turn-helix motif with two bases next to the central base pair of the 13-base pair operator sequence. The surface of the KorB DNA-binding domain mirrors the overall acidity of KorB, whereas DNA binding occurs via a basic interaction surface. We present a model of KorB, including the structure of its dimerization domain, and discuss its interactions with the highly basic ParA homolog IncC.
