Entry Detail
PDB ID:
1P51
Title:
Anabaena HU-DNA cocrystal structure (AHU6)
Biological Source:
Source Organism:
Host Organism:
PDB Version:
Deposition Date:
2003-04-24
Release Date:
2003-05-13
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.33
R-Value Work:
0.28
R-Value Observed:
0.29
Space Group:
P 1 21 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Description:DNA-binding protein HU
Chain IDs:E (auth: A), F (auth: B), G (auth: C), H (auth: D)
Chain Length:94
Number of Molecules:4
Biological Source:Anabaena sp.
Polymer Type:polydeoxyribonucleotide
Description:5'-D(*GP*CP*AP*TP*AP*TP*CP*AP*AP*TP*TP*TP*GP*TP*TP*GP*CP*AP*T)-3'
Chain IDs:A (auth: E), B (auth: F), C (auth: I), D (auth: H)
Chain Length:19
Number of Molecules:4
Biological Source:
Primary Citation
Flexible DNA bending in HU-DNA cocrystal structures
Embo J. 22 3749 3760 (2003)
PMID: 12853489 DOI: 10.1093/emboj/cdg351

Abstact

HU and IHF are members of a family of prokaryotic proteins that interact with the DNA minor groove in a sequence-specific (IHF) or non-specific (HU) manner to induce and/or stabilize DNA bending. HU plays architectural roles in replication initiation, transcription regulation and site-specific recombination, and is associated with bacterial nucleoids. Cocrystal structures of Anabaena HU bound to DNA (1P71, 1P78, 1P51) reveal that while underlying proline intercalation and asymmetric charge neutralization mechanisms of DNA bending are similar for IHF and HU, HU stabilizes different DNA bend angles ( approximately 105-140 degrees ). The two bend angles within a single HU complex are not coplanar, and the resulting dihedral angle is consistent with negative supercoiling. Comparison of HU-DNA and IHF-DNA structures suggests that sharper bending is correlated with longer DNA binding sites and smaller dihedral angles. An HU-induced bend may be better modeled as a hinge, not a rigid bend. The ability to induce or stabilize varying bend angles is consistent with HU's role as an architectural cofactor in many different systems that may require differing geometries.
