Entry Detail
PDB ID:
1NU6
Keywords:
Title:
Crystal structure of human Dipeptidyl Peptidase IV (DPP-IV)
Biological Source:
Source Organism:
Host Organism:
PDB Version:
Deposition Date:
2003-01-31
Release Date:
2003-08-26
Method Details:
Experimental Method:
Resolution:
2.10 Å
R-Value Free:
0.26
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Description:Dipeptidyl peptidase IV
Chain IDs:A, B
Chain Length:728
Number of Molecules:2
Biological Source:Homo sapiens
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Primary Citation
Structural Basis of Proline-Specific Exopeptidase Activity as Observed in Human Dipeptidyl Peptidase-IV.
Structure 11 947 959 (2003)
PMID: 12906826 DOI: 10.1016/S0969-2126(03)00160-6

Abstact

Inhibition of dipeptidyl peptidase IV (DPP-IV), the main glucagon-like peptide 1 (GLP1)-degrading enzyme, has been proposed for the treatment of type II diabetes. We expressed and purified the ectodomain of human DPP-IV in Pichia pastoris and determined the X-ray structure at 2.1 A resolution. The enzyme consists of two domains, the catalytic domain, with an alpha/beta hydrolase fold, and a beta propeller domain with an 8-fold repeat of a four-strand beta sheet motif. The beta propeller domain contributes two important functions to the molecule that have not been reported for such structures, an extra beta sheet motif that forms part of the dimerization interface and an additional short helix with a double Glu sequence motif. The Glu motif provides recognition and a binding site for the N terminus of the substrates, as revealed by the complex structure with diprotin A, a substrate with low turnover that is trapped in the tetrahedral intermediate of the reaction in the crystal.
