1MNM image
Deposition Date 1997-11-03
Release Date 1998-03-18
Last Version Date 2023-08-02
Entry Detail
PDB ID:
1MNM
Title:
YEAST MATALPHA2/MCM1/DNA TERNARY TRANSCRIPTION COMPLEX CRYSTAL STRUCTURE
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.25 Å
R-Value Free:
0.28
R-Value Work:
0.24
R-Value Observed:
0.24
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PROTEIN (MCM1 TRANSCRIPTIONAL REGULATOR)
Gene (Uniprot):MCM1
Chain IDs:C (auth: A), D (auth: B)
Chain Length:100
Number of Molecules:2
Biological Source:Saccharomyces cerevisiae
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PROTEIN (MAT ALPHA-2 TRANSCRIPTIONAL REPRESSOR)
Chain IDs:E (auth: C), F (auth: D)
Chain Length:87
Number of Molecules:2
Biological Source:Saccharomyces cerevisiae
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (STE6 OPERATOR DNA)
Chain IDs:A (auth: E)
Chain Length:26
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (STE6 OPERATOR DNA)
Chain IDs:B (auth: F)
Chain Length:26
Number of Molecules:1
Biological Source:synthetic construct
Primary Citation
Crystal structure of the yeast MATalpha2/MCM1/DNA ternary complex.
Nature 391 660 666 (1998)
PMID: 9490409 DOI: 10.1038/35563

Abstact

The structure of a complex containing the homeodomain repressor protein MATalpha2 and the MADS-box transcription factor MCM1 bound to DNA has been determined by X-ray crystallography at 2.25 A resolution. It reveals the protein-protein interactions responsible for cooperative binding of MATalpha2 and MCM1 to DNA. The otherwise flexible amino-terminal extension of the MATalpha2 homeodomain forms a beta-hairpin that grips the MCM1 surface through parallel beta-strand hydrogen bonds and close-packed, predominantly hydrophobic, side chains. DNA bending induced by MCM1 brings the two proteins closer together, facilitating their interaction. An unusual feature of the complex is that an eight-amino-acid sequence adopts an alpha-helical conformation in one of two copies of the MATalpha2 monomer and a beta-strand conformation in the other. This 'chameleon' sequence of MATalpha2 may be important for recognizing natural operator sites.
