1K2D image
Deposition Date 2001-09-26
Release Date 2003-03-04
Last Version Date 2024-10-16
Entry Detail
PDB ID:
1K2D
Keywords:
Title:
Crystal structure of the autoimmune MHC class II I-Au complexed with myelin basic protein 1-11 at 2.2A
Biological Source:
Source Organism:
Mus musculus (Taxon ID: 10090)
(Taxon ID: )
Method Details:
Experimental Method:
Resolution:
2.20 Å
R-Value Free:
0.27
R-Value Work:
0.24
R-Value Observed:
0.24
Space Group:
C 2 2 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:H-2 class II histocompatibility antigen, A-U alpha chain
Gene (Uniprot):H2-Aa
Chain IDs:A
Chain Length:189
Number of Molecules:1
Biological Source:Mus musculus
Polymer Type:polypeptide(L)
Molecule:H-2 class II histocompatibility antigen, A-U beta chain
Chain IDs:B
Chain Length:189
Number of Molecules:1
Biological Source:Mus musculus
Polymer Type:polypeptide(L)
Molecule:Myelin Basic Protein peptide with 8 residue linker peptide
Chain IDs:C (auth: P)
Chain Length:23
Number of Molecules:1
Biological Source:
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Ligand Molecules
Primary Citation
Structural snapshot of aberrant antigen presentation linked to autoimmunity: the immunodominant epitope of MBP complexed with I-Au
IMMUNITY 17 83 94 (2002)
PMID: 12150894 DOI: 10.1016/S1074-7613(02)00340-0

Abstact

Murine experimental allergic encephalomyelitis (EAE) is a useful model for the demyelinating, autoimmune disease multiple sclerosis. In the EAE system, the immunodominant N-terminal epitope of myelin basic protein (MBP) is an unusually short, weakly binding peptide antigen which elicits highly biased TCR chain usage. In the 2.2 A crystal structure of I-A(u)/MBP1-11 complex, only MBP residues 1-7 are bound toward one end of the peptide binding cleft. The fourth residue of MBP1-11 is located in an incompatible p6 pocket of I-A(u), thus explaining the short half-life of I-A(u) complexed with Ac1-11. MBP peptides extended at the C terminus of Ac1-11 result in dramatic affinity increases, likely attributed to register shifting to a higher affinity cryptic epitope, which could potentially mask the presentation of the immunodominant MBP1-11 peptide during thymic education.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
