1K23 image
Deposition Date 2001-09-26
Release Date 2001-10-31
Last Version Date 2024-10-16
Entry Detail
PDB ID:
1K23
Keywords:
Title:
Inorganic Pyrophosphatase (Family II) from Bacillus subtilis
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
3.00 Å
R-Value Free:
0.29
R-Value Work:
0.26
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Manganese-dependent inorganic pyrophosphatase
Gene (Uniprot):ppaC
Chain IDs:A, B, C, D
Chain Length:309
Number of Molecules:4
Biological Source:Bacillus subtilis
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
Primary Citation
The "open" and "closed" structures of the type-C inorganic pyrophosphatases from Bacillus subtilis and Streptococcus gordonii.
J.Mol.Biol. 313 797 811 (2001)
PMID: 11697905 DOI: 10.1006/jmbi.2001.5070

Abstact

Recently, a new class of soluble inorganic pyrophosphatase (type-C PPase) has been described that is not homologous in amino acid sequence or kinetic properties to the well-studied PPases (types A and B) found in many organisms from bacteria to humans and thought to be essential to the cell. Structural studies of the type-C PPases from Streptococcus gordonii and Bacillus subtilis reveal a homodimeric structure, with each polypeptide folding into two domains joined by a flexible hinge. The active site, formed at the interface between the N and C-terminal domains, binds two manganese ions approximately 3.6 A apart in a conformation resembling binuclear metal centres found in other hydrolytic enzymes. An activated water molecule bridging the two metal ions is likely poised for nucleophilic attack of the substrate. Importantly, the S. gordonii and B. subtilis enzymes have crystallised in strikingly different conformations. In both subunits of the S. gordonii crystal structure (1.5 A resolution) the C-terminal domain is positioned such that the active site is occluded, with a sulphate ion bound in the active site. In contrast, in the B. subtilis structure (3.0 A resolution) the C-terminal domain is rotated by about 90 degrees, leaving the active site wide open and accessible for substrate binding.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
