1H2R image
Deposition Date 1999-06-14
Release Date 2000-01-05
Last Version Date 2023-08-09
Entry Detail
PDB ID:
1H2R
Keywords:
Title:
THREE-DIMENSIONAL STRUCTURE OF NI-FE HYDROGENASE FROM DESULFIVIBRIO VULGARIS MIYAZAKI F IN THE REDUCED FORM AT 1.4 A RESOLUTION
Biological Source:
Source Organism:
Method Details:
Experimental Method:
Resolution:
1.40 Å
R-Value Free:
0.25
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:PROTEIN (PERIPLASMIC [NIFE] HYDROGENASE LARGE SUBUNIT)
Gene (Uniprot):hydB
Chain IDs:B (auth: L)
Chain Length:534
Number of Molecules:1
Biological Source:Desulfovibrio vulgaris str. 'Miyazaki F'
Polymer Type:polypeptide(L)
Molecule:PROTEIN (PERIPLASMIC [NIFE] HYDROGENASE SMALL SUBUNIT)
Gene (Uniprot):hydA
Chain IDs:A (auth: S)
Chain Length:267
Number of Molecules:1
Biological Source:Desulfovibrio vulgaris str. 'Miyazaki F'
Primary Citation
Removal of the bridging ligand atom at the Ni-Fe active site of [NiFe] hydrogenase upon reduction with H2, as revealed by X-ray structure analysis at 1.4 A resolution.
Structure Fold.Des. 7 549 556 (1999)
PMID: 10378274 DOI: 10.1016/S0969-2126(99)80071-9

Abstact

BACKGROUND: The active site of [NiFe] hydrogenase, a heterodimeric protein, is suggested to be a binuclear Ni-Fe complex having three diatomic ligands to the Fe atom and three bridging ligands between the Fe and Ni atoms in the oxidized form of the enzyme. Two of the bridging ligands are thiolate sidechains of cysteinyl residues of the large subunit, but the third bridging ligand was assigned as a non-protein monatomic sulfur species in Desulfovibrio vulgaris Miyazaki F hydrogenase. RESULTS: The X-ray crystal structure of the reduced form of D. vulgaris Miyazaki F [NiFe] hydrogenase has been solved at 1.4 A resolution and refined to a crystallographic R factor of 21.8%. The overall structure is very similar to that of the oxidized form, with the exception that the third monatomic bridge observed at the Ni-Fe site in the oxidized enzyme is absent, leaving this site unoccupied in the reduced form. CONCLUSIONS: The unusual ligand structure found in the oxidized form of D. vulgaris Miyazaki F [NiFe] hydrogenase was confirmed in the reduced form of the enzyme, with the exception that the electron density assigned to the monatomic sulfur bridge had almost disappeared. On the basis of this finding, as well as the observation that H2S is liberated from the oxidized enzyme under an atmosphere of H2 in the presence of its electron carrier, it was postulated that the monatomic sulfur bridge must be removed for the enzyme to be activated. A possible mechanism for the catalytic action of the hydrogenase is proposed.
