1GZU image
Deposition Date 2002-06-06
Release Date 2002-07-05
Last Version Date 2024-11-13
Entry Detail
PDB ID:
1GZU
Keywords:
Title:
Crystal Structure of Human Nicotinamide Mononucleotide Adenylyltransferase in Complex with NMN
Biological Source:
Source Organism:
HOMO SAPIENS (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.90 Å
R-Value Free:
0.28
R-Value Work:
0.24
R-Value Observed:
0.24
Space Group:
C 2 2 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:NICOTINAMIDE MONONUCLEOTIDE ADENYLYL TRANSFERASE
Gene (Uniprot):NMNAT1
Chain IDs:A, B, C
Chain Length:290
Number of Molecules:3
Biological Source:HOMO SAPIENS
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
Primary Citation
Crystal structure of human nicotinamide mononucleotide adenylyltransferase in complex with NMN.
FEBS Lett. 516 239 244 (2002)
PMID: 11959140 DOI: 10.1016/S0014-5793(02)02556-5

Abstact

The final step in the biosynthesis of nicotinamide-adenine dinucleotide, a major coenzyme in cellular redox reactions and involved in intracellular signaling, is catalyzed by the enzyme nicotinamide mononucleotide adenylyltransferase (NMNAT). The X-ray structure of human NMNAT in complex with nicotinamide mononucleotide was solved by the single-wavelength anomalous dispersion method at a resolution of 2.9 A. Human NMNAT is a symmetric hexamer whose subunit is formed by a large six-stranded parallel beta-sheet with helices on both sides. Human NMNAT displays a different oligomerization compared to the archaeal enzyme. The protein-nicotinamide mononucleotide interaction pattern provides insight into ligand binding in the human enzyme.
