1FOI image
Deposition Date 2000-08-28
Release Date 2001-07-20
Last Version Date 2024-02-07
Entry Detail
PDB ID:
1FOI
Keywords:
Title:
BOVINE ENDOTHELIAL NITRIC OXIDE SYNTHASE HEME DOMAIN COMPLEXED WITH 1400W(H4B-FREE)
Biological Source:
Source Organism:
Bos taurus (Taxon ID: 9913)
Host Organism:
Method Details:
Experimental Method:
Resolution:
1.93 Å
R-Value Free:
0.25
R-Value Work:
0.22
R-Value Observed:
0.22
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:NITRIC-OXIDE SYNTHASE
Gene (Uniprot):NOS3
Chain IDs:A, B
Chain Length:444
Number of Molecules:2
Biological Source:Bos taurus
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
CYS A CYS lost one O of the cacodylate group
Primary Citation
Crystallographic studies on endothelial nitric oxide synthase complexed with nitric oxide and mechanism-based inhibitors.
Biochemistry 40 5399 5406 (2001)
PMID: 11331003 DOI: 10.1021/bi002658v

Abstact

The crystal structure of the endothelial nitric oxide synthase (NOS) heme domain complexed with NO reveals close hydrogen bonding interactions between NO and the terminal guanidino nitrogen of the substrate, L-arginine. Dioxygen is expected to bind in a similar mode which will facilitate proton abstraction from L-Arg to dioxygen, a required step for O-O bond cleavage. Structures of mechanism-based NOS inhibitors, N(5)-(1-iminoethyl)-L-ornithine and N-(3-(aminomethyl)benzyl)acetamidine, provide clues on how this class of compounds operate as suicide substrate inhibitors leading to heme oxidation.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
