1EQN image
Deposition Date 2000-04-05
Release Date 2000-06-30
Last Version Date 2024-11-06
Entry Detail
PDB ID:
1EQN
Keywords:
Title:
E.COLI PRIMASE CATALYTIC CORE
Biological Source:
Source Organism:
Escherichia coli (Taxon ID: 562)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.90 Å
R-Value Free:
0.27
R-Value Work:
0.21
R-Value Observed:
0.22
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA PRIMASE
Gene (Uniprot):dnaG
Chain IDs:A, B, C, D, E
Chain Length:321
Number of Molecules:5
Biological Source:Escherichia coli
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Ligand Molecules
Primary Citation
A TOPRIM domain in the crystal structure of the catalytic core of Escherichia coli primase confirms a structural link to DNA topoisomerases.
J.Mol.Biol. 300 353 362 (2000)
PMID: 10873470 DOI: 10.1006/jmbi.2000.3844

Abstact

Primases synthesize short RNA strands on single-stranded DNA templates, thereby generating the hybrid duplexes required for the initiation of synthesis by DNA polymerases. We present the crystal structure of the catalytic unit of a primase enzyme, that of a approximately 320 residue fragment of Escherichia coli primase, determined at 2.9 A resolution. Central to the catalytic unit is a TOPRIM domain that is strikingly similar in its structure to that of corresponding domains in DNA topoisomerases, but is unrelated to the catalytic centers of other DNA or RNA polymerases. The catalytic domain of primase is crescent-shaped, and the concave face of the crescent is predicted to accommodate about 10 base-pairs of RNA-DNA duplex in a loose interaction, thereby limiting processivity.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
