1E1R image
Deposition Date 2000-05-10
Release Date 2000-06-28
Last Version Date 2023-12-06
Entry Detail
PDB ID:
1E1R
Title:
BOVINE MITOCHONDRIAL F1-ATPASE INHIBITED BY MG2+ADP AND ALUMINIUM FLUORIDE
Biological Source:
Source Organism:
BOS TAURUS (Taxon ID: 9913)
Method Details:
Experimental Method:
Resolution:
2.50 Å
R-Value Free:
0.28
R-Value Work:
0.21
Space Group:
P 21 21 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:BOVINE MITOCHONDRIAL F1-ATPASE
Gene (Uniprot):ATP5F1A
Chain IDs:A, B, C
Chain Length:510
Number of Molecules:3
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:BOVINE MITOCHONDRIAL F1-ATPASE
Gene (Uniprot):ATP5F1B
Chain IDs:D, E, F
Chain Length:482
Number of Molecules:3
Biological Source:BOS TAURUS
Polymer Type:polypeptide(L)
Molecule:BOVINE MITOCHONDRIAL F1-ATPASE
Gene (Uniprot):ATP5F1C
Chain IDs:G
Chain Length:272
Number of Molecules:1
Biological Source:BOS TAURUS
Primary Citation

Abstact

BACKGROUND: The globular domain of the membrane-associated F(1)F(o)-ATP synthase complex can be detached intact as a water-soluble fragment known as F(1)-ATPase. It consists of five different subunits, alpha, beta, gamma, delta and epsilon, assembled with the stoichiometry 3:3:1:1:1. In the crystal structure of bovine F(1)-ATPase determined previously at 2.8 A resolution, the three catalytic beta subunits and the three noncatalytic alpha subunits are arranged alternately around a central alpha-helical coiled coil in the gamma subunit. In the crystals, the catalytic sites have different nucleotide occupancies. One contains the triphosphate form of the nucleotide, the second contains the diphosphate, and the third is unoccupied. Fluoroaluminate complexes have been shown to mimic the transition state in several ATP and GTP hydrolases. In order to understand more about its catalytic mechanism, F(1)-ATPase was inhibited with Mg(2+)ADP and aluminium fluoride and the structure of the inhibited complex was determined by X-ray crystallography. RESULTS: The structure of bovine F(1)-ATPase inhibited with Mg(2+)ADP and aluminium fluoride determined at 2.5 A resolution differs little from the original structure with bound AMP-PNP and ADP. The nucleotide occupancies of the alpha and beta subunits are unchanged except that both aluminium trifluoride and Mg(2+)ADP are bound in the nucleotide-binding site of the beta(DP) subunit. The presence of aluminium fluoride is accompanied by only minor adjustments in the surrounding protein. CONCLUSIONS: The structure appears to mimic a possible transition state. The coordination of the aluminofluoride group has many features in common with other aluminofluoride-NTP hydrolase complexes. Apparently, once nucleotide is bound to the catalytic beta subunit, no additional major structural changes are required for catalysis to occur.
