1DBH image
Deposition Date 1998-12-17
Release Date 1998-12-23
Last Version Date 2024-11-13
Entry Detail
PDB ID:
1DBH
Keywords:
Title:
DBL AND PLECKSTRIN HOMOLOGY DOMAINS FROM HSOS1
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.30 Å
R-Value Free:
0.26
R-Value Work:
0.22
R-Value Observed:
0.22
Space Group:
C 1 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PROTEIN (HUMAN SOS 1)
Gene (Uniprot):SOS1
Chain IDs:A
Chain Length:354
Number of Molecules:1
Biological Source:Homo sapiens
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MSE A MET SELENOMETHIONINE
Primary Citation
Crystal structure of the Dbl and pleckstrin homology domains from the human Son of sevenless protein.
Cell(Cambridge,Mass.) 95 259 268 (1998)
PMID: 9790532 DOI: 10.1016/S0092-8674(00)81756-0

Abstact

Proteins containing Dbl homology (DH) domains activate Rho-family GTPases by functioning as specific guanine nucleotide exchange factors. All known DH domains have associated C-terminal pleckstrin homology (PH) domains that are implicated in targeting and regulatory functions. The crystal structure of a fragment of the human Son of sevenless protein containing the DH and PH domains has been determined at 2.3 A resolution. The entirely alpha-helical DH domain is unrelated in architecture to other nucleotide exchange factors. The active site of the DH domain, identified on the basis of sequence conservation and structural features, lies near the interface between the DH and PH domains. The structure suggests that ligation of the PH domain will be coupled structurally to the GTPase binding site.
