ISDA: 1C1Y

Deposition Date 1999-07-22

Release Date 1999-08-02

Last Version Date 2024-02-07

Entry Detail

PDB ID:

1C1Y

Keywords:

SIGNALING PROTEIN

Title:

CRYSTAL STRUCTURE OF RAP.GMPPNP IN COMPLEX WITH THE RAS-BINDING-DOMAIN OF C-RAF1 KINASE (RAFRBD).

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

1.90 Å

R-Value Free:

0.25

R-Value Work:

0.22

R-Value Observed:

0.22

Space Group:

P 21 21 21

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:RAS-RELATED PROTEIN RAP-1A
Gene (Uniprot):RAP1A
Chain IDs:A
Chain Length:167
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P62834 Pfam ID:PF00071

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:PROTO-ONCOGENE SERINE/THREONINE PROTEIN KINASE RAF-1
Gene (Uniprot):RAF1
Chain IDs:B
Chain Length:77
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P04049 Pfam ID:PF02196 EC:2.7.10.2

Ligand Molecules

GTP

Primary Citation

The 2.2 A crystal structure of the Ras-binding domain of the serine/threonine kinase c-Raf1 in complex with Rap1A and a GTP analogue.

Nassar, N, Nassar, N, Rehmann, H, Arias-Palomo, E, Hadders, M.A, Schwede, F, Llorca, O, Bos, J.L.Show

Nature 375 554 560 (1995)

PMID: 7791872 DOI: 10.1038/375554a0

Abstact

The X-ray crystal structure of the complex between the Ras-related protein Rap1A in the GTP-analogue (GppNHp) form and the Ras-binding domain (RBD) of the Ras effector molecule c-Raf1, a Ser/Thr-specific protein kinase, has been solved to a resolution of 2.2 A. It shows that RBD has the ubiquitin superfold and that the structure of Rap1A is very similar to that of Ras. The interaction between the two proteins is mediated by an apparent central antiparallel beta-sheet formed by strands B1-B2 from RBD and strands beta 2-beta 3 from Rap1A. Complex formation is mediated by main-chain and side-chain interactions of the so-called effector residues in the switch I region of Rap1A.
