Deposition Date 1998-09-21
Release Date 1999-02-23
Last Version Date 2023-08-09
Entry Detail
PDB ID:
1BVY
Keywords:
Title:
COMPLEX OF THE HEME AND FMN-BINDING DOMAINS OF THE CYTOCHROME P450(BM-3)
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.03 Å
R-Value Free:
0.27
R-Value Observed:
0.18
Space Group:
P 21 21 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PROTEIN (CYTOCHROME P450 BM-3)
Gene (Uniprot):cyp102A1
Chain IDs:A, C (auth: B)
Chain Length:458
Number of Molecules:2
Biological Source:Bacillus megaterium
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PROTEIN (CYTOCHROME P450 BM-3)
Gene (Uniprot):cyp102A1
Chain IDs:B (auth: F)
Chain Length:191
Number of Molecules:1
Biological Source:Bacillus megaterium
Primary Citation
Structure of a cytochrome P450-redox partner electron-transfer complex.
Proc.Natl.Acad.Sci.USA 96 1863 1868 (1999)
PMID: 10051560 DOI: 10.1073/pnas.96.5.1863

Abstact

The crystal structure of the complex between the heme- and FMN-binding domains of bacterial cytochrome P450BM-3, a prototype for the complex between eukaryotic microsomal P450s and P450 reductase, has been determined at 2.03 A resolution. The flavodoxin-like flavin domain is positioned at the proximal face of the heme domain with the FMN 4.0 and 18.4 A from the peptide that precedes the heme-binding loop and the heme iron, respectively. The heme-binding peptide represents the most efficient and coupled through-bond electron pathway to the heme iron. Substantial differences between the FMN-binding domains of P450BM-3 and microsomal P450 reductase, observed around the flavin-binding sites, are responsible for different redox properties of the FMN, which, in turn, control electron flow to the P450.
